Centralized Logging with EFK on GCP

Introduction

Effective log management is critical for monitoring, troubleshooting, and analyzing applications in real-time. In this post, we’re beginning a series on logging and management by setting up a centralized logging solution using Elasticsearch and Kibana with X-Pack security enabled. This ensures controlled access with user authentication.

We’ll deploy Elasticsearch and Kibana as Docker containers on a Google Cloud Platform (GCP) VM instance. Once the centralized logging system is set up, we’ll configure Fluentd to ship NGINX access logs to Elasticsearch for centralized monitoring.

Part 1: Setting Up the Centralized Server

Step 1: Create a GCP VM Instance

Log in to your GCP Console and navigate to Compute Engine > VM Instances.
Create a new instance with the following specifications:
- Name: logging-server
- Machine type: e2-medium (or higher, depending on traffic)
- Boot disk: Ubuntu 20.04 LTS
- Firewall: Allow HTTP and HTTPS traffic
SSH into the instance once it’s up and running.

Step 2: Install Docker on the VM

Update the VM and install Docker:

sudo apt update && sudo apt upgrade -y
sudo apt install -y docker.io
sudo systemctl enable --now docker

Step 3: Deploy Elasticsearch with X-Pack Security

Create a directory for Elasticsearch data:

 mkdir -p ~/elasticsearch_data
 sudo chmod 777 ~/elasticsearch_data

Run the Elasticsearch container with X-Pack enabled:

 docker run -d --name elasticsearch \
   -e "discovery.type=single-node" \
   -e "xpack.security.enabled=true" \
   -e "ELASTIC_PASSWORD=elastic123" \
   -v ~/elasticsearch_data:/usr/share/elasticsearch/data \
   -p 9200:9200 -p 9300:9300 \
   docker.elastic.co/elasticsearch/elasticsearch:8.10.1

Verify Elasticsearch is running:
```
 curl -u elastic:elastic123 http://<VM_EXTERNAL_IP>:9200
```
Replace <VM_EXTERNAL_IP> with your instance’s external IP address.

You should see a JSON response confirming Elasticsearch is active.

Step 4: Deploy Kibana

Run the Kibana container:

 docker run -d --name kibana \
   -e "ELASTICSEARCH_HOSTS=http://<VM_EXTERNAL_IP>:9200" \
   -e "ELASTICSEARCH_USERNAME=elastic" \
   -e "ELASTICSEARCH_PASSWORD=elastic123" \
   -p 5601:5601 \
   docker.elastic.co/kibana/kibana:8.10.1

Access Kibana in your browser at http://<VM_EXTERNAL_IP>:5601.
Use the elastic username and elastic123 password to log in.

Part 2: Shipping Logs with Fluentd

Step 1: Install Fluentd

On the server running NGINX (can be the same VM or another server):

Add the Fluentd repository:

 curl -fsSL https://packages.treasuredata.com/GPG-KEY-td-agent | sudo apt-key add -
 echo "deb http://packages.treasuredata.com/4/ubuntu/focal/ focal contrib" | sudo tee /etc/apt/sources.list.d/td-agent.list
 sudo apt update

Install Fluentd:
```
 sudo apt install -y td-agent
```

Step 2: Configure Fluentd for NGINX Logs

Install the Elasticsearch plugin for Fluentd:

 sudo /usr/sbin/td-agent-gem install fluent-plugin-elasticsearch

Update Fluentd’s configuration to ship logs to Elasticsearch. Open the configuration file:

 sudo nano /etc/td-agent/td-agent.conf

Add the following configuration:

 <source>
   @type tail
   path /var/log/nginx/access.log
   pos_file /var/log/td-agent/nginx-access.log.pos
   tag nginx.access
   format nginx
 </source>

 <match nginx.access>
   @type elasticsearch
   host <VM_EXTERNAL_IP>
   port 9200
   scheme http
   logstash_format true
   user elastic
   password elastic123
 </match>

Restart Fluentd:
```
 sudo systemctl restart td-agent
```

Step 3: Verify Logs in Kibana

Generate some logs by accessing your NGINX server:
```
 curl http://<NGINX_SERVER_IP>
```
In Kibana, go to Discover and create an index pattern for logstash-*.
You should see the NGINX logs appearing in real-time.
Create a Data View to analyze the index better and run queries.

Best Practices

Secure Access: Ensure your Elasticsearch and Kibana instances are behind a firewall or protected using IP whitelisting.
Persistent Data: Use persistent disks for Elasticsearch data to prevent data loss on container restarts.
Resource Management: Monitor resource usage and scale the VM as needed to handle increased log volumes.
Log Rotation: Set up log rotation on the Fluentd source (e.g., NGINX logs) to prevent disk exhaustion.

Conclusion

This setup provides a robust centralized logging system with Elasticsearch and Kibana, secured by X-Pack authentication. By using Fluentd to ship logs, you can monitor and analyze NGINX logs or any other application logs from a single interface.

In the next post, we’ll expand this setup to handle high-volume production traffic and discuss advanced index management techniques. Stay tuned!

Have questions or insights? Share them in the comments below or reach out on LinkedIn!
